new products heater solar heating system solar water heater price

FOB Reference Price:Get Latest Price
$100.00 - $300.00 / Set | 1 Set/Sets (Min. Order)
Pressure:
Unpressurized
Heating System:
Thermosyphon (Passive)
Lead Time:
Quantity(Sets) 1 - 100 >100
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Graphic customization (Min. Order: 1 Sets)

More

Customized packaging (Min. Order: 1 Sets) Less
Samples:
$999.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
ENSUN
Model Number:
CNP77
Type:
Evacuated Tube
Installation:
Freestanding
Certification:
CE, RoHS, ISO9001, CE,ISO
Circulation Type:
Direct / Open Loop (Active)
Connection Type:
Direct-Plug
Capacity:
300
Housing Material:
Stainless Steel, Plastic,Stainless Steel
Item Name:
solar water heater
Color:
Any solar hot water heater
Pressure:
Unpressurized solar hot water heater
Logo:
OEM
Use:
Bathroom
Size:
Custom Made
Package:
Standard carton for vacuum tube solar water heater.
Heating System:
Thermosyphon (Passive)
Supply Ability
Supply Ability:
100000 Set/Sets per Year
Packaging & Delivery
Packaging Details
solar water heater
Standard carton for vacuum tube solar water heater
Port
Shanghai, China
Lead Time :
Quantity(Sets) 1 - 100 >100
Est. Time(days) 15 To be negotiated


Product Description



new products heater solar heating system solar water heater price

Compactg non pressure solar water heater relies on the nature circulation of the water between solar tubes

and the water tank. Thermosyphon systems work on principal of heat rising. The water enters in the bottom

of the collector and rises to the tank as it warms. The advantage of this system is that solar heat is stored

in a well-insulated tank, so hot water can be used at any time without the penalty of overnight losses.

Moreover the insulation of the tank can protect heat during 3 days without heat loss.






Specification:
Solar heat storage tank diameter(mm)420/460/470/480
Thickness,insulated(mm)50/60
Vent connection(inch)1/2
Electric heater connection(inch)47
Water connection(inch)1/2 or 3/4
Frame angle(degree)23/25/30/45
Feature:

1.Super anti-erode outer tank:Outer tank is made by stainless steel 304or PVDF.Best

anti-erode material,Especial for the seaside area,such as East South Asia,Mexico etc.

2.Feeding water automatic:with special design,feeding water automatic,and ensure the

outlet water as stable temperature.

3.We design to install eith the solar PV panel supplying the lighting and the cell

dhone charger.

Material:
1.Inner tank:stainless steel SUS304
2.Vacuum tube:QB-AL-N/AL-47*1500/58*1800
3.Outer tank:stainless steel SUS304/SUS316/PVDF color steel
4.Frame:coated galvanized steel -1.5mm;Aliminum alloy steel2.0mm
5.The material of insulation:polyurethane50/60mm
6.The reflector:aluminum component;AL 99.85% surface oxidation;stainless steel.




New-Design-Manufacture-In-China-Solar-Hot (1).jpgNew-Design-Manufacture-In-China-Solar-Hot (3).jpgNew-Design-Manufacture-In-China-Solar-Hot (5).jpg



1.Features:
(1). Cheap and reliable solution, Simple structures, Easy installation.
(2). High efficiency of heating,water heated by sun light directly.
(3). Withstands water pressure no more than 0.1MPa.
(4). Operated without any power supplying.
(5). Electric heater can be used as back-up in rainy days.
(6). Hot water can be used directly, or can be used as a pre-heated.
(7). Water flow in the vacuum tubes and is operated when confined.
(8). Tank is equipped with electric water heater setting, automatic temperature controller(optional ).
(9). the insulating layer uses polyurethane bulk bubble,keep hot water 72 hours.



2.How to choose:
Choose the item according to the capacity, and choose the capacity according to the people quantity
in your family, one adult shower need about 50 L water. Normally,50 liters is only used for one person's shower.
