skillful manufacture pool heater solar panels

FOB Reference Price:Get Latest Price
$100.00 - $300.00 / Set | 1 Set/Sets (Min. Order)
Pressure:
Unpressurized
Heating System:
Thermosyphon (Passive)
Lead Time:
Quantity(Sets) 1 - 100 >100
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Samples:
$999.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
ENSUN-pool heater, ENSUN
Model Number:
D9A66
Type:
Evacuated Tube
Installation:
Freestanding
Certification:
CE, RoHS, ISO9001, CE,ISO
Circulation Type:
Direct / Open Loop (Active)
Connection Type:
Direct-Plug
Capacity:
300
Housing Material:
Stainless Steel, Stainless Steel
Item:
pool heater solar panels
Color:
Any camping solar heaters
Pressure:
Unpressurized
Logo:
OEM
Size:
Custom Made
Package:
Standard carton for vacuum tube solar water heater
Supply Ability
Supply Ability:
100000 Set/Sets per Year pool heater solar panels
Packaging & Delivery
Packaging Details
pool heater solar panels
Standard carton for vacuum tube solar water heater
Port
shanghai
Lead Time :
Quantity(Sets) 1 - 100 >100
Est. Time(days) 15 To be negotiated

final_01

Product Description

Compact non pressure solar water heater relies on the nature circulation of the water between solar tubes

and the water tank. Thermosyphon systems work on principal of heat rising. The water enters in the bottom

of the collector and rises to the tank as it warms. The advantage of this system is that solar heat is stored

in a well-insulated tank, so hot water can be used at any time without the penalty of overnight losses.

Moreover the insulation of the tank can protect heat during 3 days without heat loss.

 _D9A6725-4_D9A6723-2 (2)_D9A6767-7



1.Features:
(1). Cheap and reliable solution, Simple structures, Easy installation.
(2). High efficiency of heating,water heated by sun light directly.
(3). Withstands water pressure no more than 0.1MPa.
(4). Operated without any power supplying.
(5). Electric heater can be used as back-up in rainy days.
(6). Hot water can be used directly, or can be used as a pre-heated.
(7). Water flow in the vacuum tubes and is operated when confined.
(8). Tank is equipped with electric water heater setting, automatic temperature controller(optional ).
(9). the insulating layer uses polyurethane bulk bubble,keep hot water 72 hours.



2.How to choose:
Choose the item according to the capacity, and choose the capacity according to the people quantity
in your family, one adult shower need about 50 L water. Normally,50 liters is only used for one person's shower.




Descripitionall stainless steel low pressure solar water heater
Material of out tankstainless steel 0.4mm
Material of inner tank0.31-0.5mm thickness SUS304 stainless steel
Tank insulating layer55mm 45kg/m³ high-density polyurethane foamed
Inlet and outlet holeMale G 1/2, 3/4
Max pressure0.05 Mpa
Solar collector tube3.3 Borosilicate glass with Cu-SS-ALN/ANL. coating
Thickness of glass tube1.6mm
Vacuum tube tightnessP≤0.005 Pa
AbsorptionAS=0.93-0.96(AM1.5)
Emission ratioεh=0.04-0.06(80C±5C)

Idle sunning

property parameters

Y=220~260m2.C/KW

Average heat

loss coefficient

ULT=0.6~0.7W/(m2.C)
Bracket:1.4mm thickness stainless steel with paint
Structure of tank:5 holes for air vent,overflow,water inlet and outlet,electric heater
Welding:Argon arc welding
Fastening pieces:Made of stainless steel screw
Tube quantity30 tube 58x1,800mm
Tank capacity180L
Afford for house3-4persons
